SM Fiber Types
G652D/G657A1/G657A2
MM Fiber Types
OM1/OM2/OM3/OM4/OM5
Cores
8C/12C/24C
Outer Jacket Dimensions
3.0/4.0/4.5/5.0mm
OD of the Unit Cable
0.9/1.6/2.0mm
Jacket Types
PVC/LSZH/TPU/PVDF
IL
SM/Standard Loss≤0.7dB, Low Loss≤0.35dB, MM/Standard Loss≤0.5dB, Low Loss≤3.0dB
RL
SM≥55dB, MM≥35dB
Length
Customized
Branch Length
Customized
Connectors
MTP/MPO-LC or MTP/MPO-MTP-MPO, MPO to FC
Polarity
TypeA, TypeB, TypeC
MPO Connector Type
Male or Female
